Jackson crew series - Wash Heater Components

32
07610-003-78-18-N
VOLTAGE PHASE KW PART NUMBER CONTACTOR
208 1 15 04540-121-68-45 05945-003-73-22
230 1 15 04540-121-68-46 05945-003-73-22
208 3 15 04540-121-68-45 05945-003-75-02
230 3 15 04540-121-68-46 05945-003-75-02
460 3 15 04540-121-68-47 05940-003-75-02
208 1 18 04540-121-79-30 05945-003-73-22
230 1 18 04540-121-79-31 05945-003-73-22
208 3 18 04540-121-79-30 05945-003-75-02
230 3 18 04540-121-79-31 05945-003-75-02
460 3 18 04540-121-79-32 05945-003-75-02
SERVICE NOTES: When replacing wash heaters it is highly recommended to change the gasket also. Once installed,
gaskets become compressed and are subject to extreme temperature changes. Replacing the gasket with the heater may
prevent future leaks.
The nuts used to secure the heater to the casting should be torque to 16 in.-lbs. After tightening, the unit should be allowed
to heat up and operate normally for approximately 30 minutes. Secure power to the machine and check the nuts once more
to verify they are torque to 16 in.-lbs.
WASH HEATERS
PARTS
