Jackson crew series User Manual

25
07610-003-78-18-N
1 2 3 4
5 6 7 8
INPUTS
1 2 3 4
5 6 7 8
OUTPUTS
PWR
RUN
OK
PLC1
LIGHT CONFIGURATION
INPUTS:
1. ON/OFF BUTTON
2. DOOR SWITCH SAFETY INTERLOCKS
3. RACK INLET SWITCH
4. FINAL RINSE SWITCH
5. LOWER WASH FLOAT SWITCH
6. UPPER WASH FLOAT SWITCH
7. MANUAL / DELIME SWITCH
8. SPARE
OUTPUTS:
1. FINAL RINSE SOLENOID / RINSE SIGNAL RELAY
2. WASH TANK FILL SOLENOID
3. DRIVE MOTOR CONTACTOR
4. WASH MOTOR CONTACTOR
5. WASH HEATER CONTACTOR or
STEAM HEAT RELAY (Steam Units Only)
6. VENT FAN RELAY
7. N/A
8. N/A
1 2 3 4
5 6 7 8
INPUTS
1 2 3 4
5 6 7 8
OUTPUTS
PWR
RUN
OK
PLC2
LIGHT CONFIGURATION
INPUTS:
1. LOWER PRE-WASH FLOAT SWITCH (66 UNITS ONLY)
2. UPPER PRE-WASH FLOAT SWITCH (66 UNITS ONLY)
3. NOT USED
4. NOT USED
5. NOT USED
6. NOT USED
7. NOT USED
8. NOT USED
OUTPUTS:
1. PRE-WASH TANK FILL SOLENOID
2. PRE-WASH MOTOR CONTACTOR
3. NOT USED
4. NOT USED
5. NOT USED
6. NOT USED
7. N/A
8. N/A
INPUTS:
1. On/Off Switch
2. Door Switch Safety Interlocks
3. Rack Inlet Switch
4. Final Rinse Switch
5. Lower Wash Float Switch
6. Upper Wash Float Switch
7. Manual/Delime Switch
8. Side-Loader Switch (on with no rack present)
OUTPUTS:
1. Rinse Solenoid/Rinse Signal Relay
2. Wash Tank Fill Solenoid
3. Drive Motor Contactor
4. Wash Motor Contactor
5. Wash Heater Contactor or Steam Heat Relay
6. Ventilation Fan Relay
7. N/A
8. N/A
INPUTS:
1. Lower Pre-Wash Float Switch (66 Units Only)
2. Upper Pre-Wash Float Switch (66 Units Only)
3. N/A
4. N/A
5. N/A
6. N/A
7. N/A
8. N/A
OUTPUTS:
1. Pre-Wash Tank Fill Solenoid (66 Units Only)
2. Pre-Wash Motor Contactor (66 Units Only)
3. N/A
4. N/A
5. N/A
6. N/A
7. N/A
8. N/A
MAINTENANCE
TROUBLESHOOTING
