Jackson crew series User Manual

40
07610-003-78-18-N
ITEM QTY DESCRIPTION PART NUMBER
1 1 Pump & Motor Assembly See Table Below
2 1 Gasket, Pump Suction 05330-003-75-87
3 1 Gasket, Pump Discharge 05330-003-75-88
4 2 Hose Clamp, Range 2-9/16" to 3-1/2" 04730-003-15-40
5 1 Hose, Wash Pump Discharge 05700-003-77-62
6 1
(L-R Machines) Lower Manifold
(R-L Machines) Lower Manifold
05700-003-74-29
05700-003-74-28
7 1 Casting, Wash Manifold 09515-003-71-50
8 1 Tube, Manifold Riser 05700-003-72-37
9 1 Wash Manifold Weldment, Upper 05700-003-73-66
10 2 Wash Arm Weldment, Right 05700-003-75-80
11 2 Wash Arm Weldment, Left 05700-003-75-79
12 12 Cap, Threaded 04730-603-12-00
13 3 O-Ring, Silicone, .103 Dia., 2-1/2" x 2-11/16" OD 05330-003-73-71
14 4 O-Ring, Silicone, .139 Dia., 2-1/4" ID x 2-1/2" OD 05330-003-73-72
PUMP & MOTOR ASSEMBLY PART NUMBER
Wash Pump, 3HP, 208V, 60Hz, 3-Phase 06105-003-76-11
Wash Pump, 3HP, 230V, 60Hz, 3-Phase 06105-003-76-11
Wash Pump, 3HP, 460V, 60Hz, 3-Phase 06105-003-76-11
Wash Pump, 3HP, 460V, 60Hz, 1-Phase 06105-003-76-13
Wash Pump, 3HP, 230V, 60Hz, 1-Phase 06105-003-76-13
WASH MANIFOLD & ARM ASSEMBLY
PARTS
