Jackson crew series User Manual

42
07610-003-78-18-N
ITEM QTY DESCRIPTION PART NUMBER
1 1 Pump & Motor Assembly See Table Below
2 1 Gasket, Pump Suction 05330-003-75-87
3 1 Gasket, Pump Discharge 05330-003-75-88
4 2 Hose Clamp, Range 2-9/16" to 3-1/2" 04730-003-15-40
5 1 Hose, Wash Pump Discharge 05700-003-77-62
6 1 Lower Manifold (L-R Units) 05700-003-81-54
7 1 Lower Manifold (R-L Units) 05700-003-81-79
8 3 O-Ring, Silicone, .103 Dia., 2-1/2" x 2-11/16" OD 05330-003-73-71
9 2 O-Ring, Silicone, .139 Dia., 2-1/4" ID x 2-1/2" OD 05330-003-73-72
10 1 Casting, Pre-Wash Manifold 09515-003-77-22
11 1 Tube, Manifold Riser 05700-003-81-53
12 1 Wash Manifold Weldment, Upper 05700-003-81-76
13 1 Wash Arm Weldment, Left 05700-003-75-79
14 1 Wash Arm Weldment, Right 05700-003-75-80
15 1 Pre-Wash Arm Weldment, Lower 05700-003-80-96
16 4 Cap, Threaded 04730-603-12-00
PUMP & MOTOR ASSEMBLY PART NUMBER
Pre-Wash Pump, 2HP, 208V, 60Hz, 3-Phase 06105-003-76-12
Pre-Wash Pump, 2HP, 230V, 60Hz, 3-Phase 06105-003-76-12
Pre-Wash Pump, 2HP, 460V, 60Hz, 3-Phase 06105-003-76-12
Pre-Wash Pump, 2HP, 460V, 60Hz, 1-Phase 06105-003-76-14
Pre-Wash Pump, 2HP, 230V, 60Hz, 1-Phase 06105-003-76-14
PRE-WASH MANIFOLD & ARM ASSEMBLIES
PARTS
