44
07610-003-78-18-N
ITEM QTY DESCRIPTION PART NUMBER
1 3 Elbow, 90 Deg., 1/2" Brass 04730-206-08-00
2 1 Vacuum Breaker, 1/2" 04820-003-06-13
3 1 Upper Rinse Arm 05700-003-76-02
4 1 Lower Rinse Arm 05700-003-76-04
5 1 Rinse Manifold 05700-003-76-79
6 1
Rinse Injector (L-R Units)
(R-L Units)
05700-003-76-82
05700-003-76-83
7 1 Nipple, 1/2" Close Brass 04730-207-15-00
8 1 Valve, Ball Test Cock, 1/4" Bronze 04810-011-72-67
9 1 Tee, 1/2" FNPT x 1/2" FNPT x 1/4" FNPT 04730-002-22-56
10 2 Plug, 1/8" NPT Brass 04730-209-07-37
11 1 Gasket, Rinse Manifold 05330-003-75-91
12 1 Fitting, Imperial Brass 05310-924-02-05
13 1 Plug, 1/4" 04730-209-01-00
14 3 O-Ring, Silicon, .103 Dia., 11/16" x 7/8" OD 05330-003-77-82
15 1 Elbow, Brass, 90 Deg., 1/4" NPTM x 1/4" NPTF 04730-003-77-83
16 6 Locknut, 1/4-20 Hex w/Nylon Insert 05310-374-01-00
17 2 Bolt, 1/4-20 x 1/2" Long 05305-274-02-00
18 2 Lockwasher, Spring, 1/4" 05311-274-01-00
19 1 Elbow Weldment, Temp Gauge 05700-003-77-12
20 1 Gauge, 0-100# Pressure 06685-111-88-34
21 1 Decal 15-25 PSI 09905-002-97-74
22 2 End Plug 05700-011-35-92
23 1 Hose, 1/4 x 30 S/S Braided w/PTFE, Male Swivel 04720-003-76-10
RINSE ASSEMBLY
PARTS
