65
07610-003-78-18-N
ITEM QTY DESCRIPTION PART NUMBER
6 1 Elbow, 90 Deg. 3/4" Black Iron 04730-906-10-34
7 1 Reducer, 1-1/2" x 3/4" Black Iron 04730-002-36-81
8 1 Platform, J120 Steam Booster 05700-002-36-72
9 1 Regulating Valve, 3/4" 04820-100-01-06
10 2 Nipple, 3/4" x 6" Long Brass 05700-001-26-74
11 3 Elbow, 90 Deg. 3/4" Brass 04730-206-13-00
12 2 Nipple, 3/4" x 4" Long Brass 04730-207-05-00
13 2 Union, 3/4" Brass 04730-212-02-00
14 3 Nipple, 3/4" x 2" Long Brass 04730-207-46-00
15 3 Nipple, Close, 3/4" x 1-3/8" Brass 04730-207-34-00
16 2 Bushing, Hex, 1-1/4" x 3/4" Reducer 04730-011-88-80
17 2 Tee, Brass, 3/4" x 3/4" x 3/4" 04730-211-01-34
18 1 Adapter, 3/8" x 3/4" Brass 04730-011-89-19
19 1 Valve, Steam Relief, 3/4" 04820-100-07-06
20 1 Tee, Brass, 3/4" x 3/4" x 1/4" 04730-211-04-00
21 2 Valve, Ball Test Cock 1/4" Bronze 04810-011-72-67
22 2 Pressure Gauge, 1/4", 0-100 PSI 06685-111-88-34
23
23A
23B
23C
23D
23F
1
Control, J120 Assembly (Major Components Listed Below)
Thermostat, Corkscrew
Switch
Light, Red Indicating
Terminal Block, 2-Pole
Ground Lug
05700-002-98-95
06680-500-01-77
05930-011-49-55
05945-111-21-57
05940-500-09-61
05940-200-76-00
24 2 Fitting 05975-011-49-03
25 1 Reducer, 1-1/2" x 1" Black Iron 04730-002-36-79
26 6 Nipple, Close 1" x 2" Black Iron 04730-907-08-34
27 1 Elbow, 1", 90 Deg. Black Iron 04730-906-03-34
28 1 Valve, Safety Relief, 1" 04850-100-01-35
29 1 Siphon Tube, Pigtail 1/4" Black Iron 04730-907-14-34
30 1 Coupling, 1/4" Black Iron 04730-904-01-04
31 1 Tee, 1" x 1" x 1/4", Black Iron 04730-911-01-00
32 1 Y-Strainer, 1" Steam Black Iron 04730-217-02-32
33 1 Union, 3/4" Brass 04730-912-01-00
34 1 Valve, 120V, 1" Bronze Steam 04810-002-92-23
35 1 Union, 1" Black Iron 04730-912-01-34
36 1 Tee, 1" Black Iron 04730-911-01-34
PARTS
BOOSTER HEATER OPTION (STEAM)
To Next Page
