File Version: 3.4 / JAKA Zu Series Hardware User Manual
3 Safety Functions
JAKA’s robot has a series of safety functions to guarantee the safety of man-machine collaboration. This chapter
introduces these safety functions, and users should strictly abide by the requirements and precautions.
3.1
According to the IEC 60201 standard, three stop categories have been set for JAKA’s robot: stop category 0
(Cat. 0), stop category 1 (Cat.1), and stop category 2 (Cat.2). Among them, Cat.0 is uncontrollable stop, while
Cat.1 and Cat.2 are controllable stop.
If Cat. 0 is triggered, the power to the robot is immediately cut off and the robot stops running immediately.
If Cat.1 is triggered, the robot actuators remain powered until the robot stops, and the driving power supply is
disconnected after it is completely stopped.
If Cat.2 is triggered, the robot stops while maintaining the trajectory, and it remains powered after being stopped
with the programs suspended.
3.2
Safety stop time is the time it takes to stop the robot from the moment when the emergency stop button is
pressed or a safety protection function is triggered; the stop distance is the distance the end of the robot moves
during the safety stop time. Among them, pressing the emergency stop button falls into Cat.1, while triggering
the safety protection function falls into Cat.2. During this period, the robot is still moving and may harm the
personnel or other equipment. Therefore, users and integrators should consider this time and distance in risk
assessment.
The test conditions are as follows:
⚫ Reach: 100%, 66%/ 66%, 33%;
⚫ Speed: 100%, 66%, 33%;
⚫ Payload: See the table below.
See Appendix 1: Stop Time and Distance for the respective stop distance and time of Cat.1 and Cat.2.
3.3
JAKA’s robot have two configurable safety modes: the emergency stop mode and the protective stop mode.
When an emergency occurs, this mode can be triggered for protection.Users can trigger the
configuration via the emergency stop button on the remote stick, the EI interface on the control cabinet panel
P8, and the safety IO function in the safety settings.
The protective stop is a stop type triggered when the controller detects an error.The protective
stop can be triggered by the SI interfaces on P8 of the front panel of control cabinet, the safety I/O and safety
plane function in the safety settings.
When the robot is in the emergency stop and protective stop state, its states are as follows:
