JAKA Zu 3 - Bottom Panel Interfaces; Power Adaptation

File Version: 3.4  /  JAKA Zu Series Hardware User Manual
9.5 
The bottom panel of the control cabinet includes following items:
  Gigabit network port, configured for dynamic IP usage.
  Connection interface between the robot arm and control cabinet.
  Connection interface to external AC power outlet.
  Connection interface to control stick.
  Power supply control switch.
  Dedicated channel to guide external device cables.
  Used to secure cables in place.
9.5.1 
Different countries and regions have different standards, and JAKA supports corresponding plugs when
products are exported overseas.
1. China Standard Plug (National Standard): 3 I-shaped flat-pin plug
Cable
standard
Core size
Length
Cable
OD
Rated
value
Frequency
Cable
material
LN
insulation
level
RW
3×1.0 mm²
3×0.002in²
3000±50mm
118.11±1.97in
10A
250V
50Hz
PVC
2kV 1min
50Hz
2. European Standard Plug (European Standard, German Standard): F/E universal plug
Cable
standard
Core size
Length
Cable OD
Rated
value
Frequency
Cable
material
LN insulation
level
H05W-F
3×1.0 mm²
3×0.002in²
3000±50mm
118.11±1.97in
10A
250V
50Hz
PVC
2kV 1min
50Hz
3. British Standard Plug (British Standard): G-shaped plug
6.9mm
0.272in
7.2mm
0.283in
