Getting Started XT200 User Manual
Janam Technologies LLC Version 2, April 2020 Getting Started 2-4
Charging the XT200 battery
To charge the battery using the DC Power Adapter Kit:
1. Slide the appropriate US/UK/EUR adapter plug onto the AC/DC power adapter housing.
2. Insert the supplied USB cable into the AC/DC power adapter housing and the USB
port on the right side of the XT200.
3. Plug in the AC/DC power supply. The small XT200 LED indicator above the LCD
display will light red while charging and will change to green when fully charged.
To charge the battery using one of the (optional) Cradle Kits:
1. Insert the DC power plug into the DC power jack on the cradle.
Insert the XT200 into the cradle.
2. Plug in the AC/DC power supply. The XT200 LED indicator will light red while
charging and will change to green when fully charged. Use only easily accessible
wall sockets that are easily reached with the length of the supplied power cable.
