Page 3
ENGLISH
Jandy
®
, JXi
™
Gas-Fired Pool & Spa Heater
|
Installation & Operation Manual
Section 2. General Information
This manual provides installation and operation
instructions for the Jandy JXi pool and spa gas heater
product line.
Read the installation and operation instructions
completely before proceeding with the
installation.
2.1 Technical Assistance
Web:
www.jandy.com
Phone:
800.822.7933
2.1.1 Quality Promise
As industry leaders committed
to giving you the perfect pool
experience, we-
• Promise to maintain the highest quality
standards in all areas of operation.
• Promise to use high quality materials
and world-class processes to
manufacture our products.
• Promise that your equipment will arrive completely tested in pool
environments, inspected and quality-assured for reliability and durability.
• We stand by our promise.
• Our promise is backed by dedicated support and our written express
product warranty.
• What you say matters. Tell us what you think by calling
760-734-8844 or email feedback@zodiac.com
for questions or input.
2.2 Warranty
This heater is sold with a limited factory warranty.
Details are included with this heater.
Make all warranty claims to a Zodiac
®
dealer or directly
to the factory. Claims must include the heater serial
number and model (this information can be found on the
rating plate), installation date, and name of the installer.
Shipping costs are not included in the warranty coverage.
The warranty does NOT cover damage caused by
improper assembly, installation, operation or eld
modication. Also, damage to the heat exchanger by
corrosive water is NOT covered by the warranty.
NOTE: Keep this manual in a safe place for future reference when
inspecting or servicing the heater.
2.3 Consumer Information and Safety
The heater is designed and manufactured to provide
many years of safe and reliable service when installed,
operated, and maintained according to the information
in this manual and the installation codes referred to
throughout. Be sure to read and comply with all warnings
and cautions.
WARNING
Improper installation or maintenance can cause nausea or asphyxi-
ationfromcarbonmonoxideinuegaseswhichcouldresultin
severe injury, or death. For indoor installations, as an additional
measure of safety, Zodiac Pool Systems LLC strongly recommends
the installation of suitable Carbon Monoxide detectors in the vicin-
ity of this appliance and in any adjacent occupied spaces.
WARNING
The following “Safety Rules for Hot Tubs,” recommended by the U.S.
Consumer Product Safety Commission, should be observed when
using the spa. Consult heater operation and installation instructions
for water temperature guidelines before setting temperature.
• Spa or hot tub water temperature should never exceed 104°F
(40°C). One hundred degrees Fahrenheit (100°F [38°C]) is consid-
ered safe for a healthy adult. Special caution is recommended for
young children.
• The drinking of alcoholic beverages before or during spa or
hot tub use can cause drowsiness which could lead to uncon-
sciousness, and subsequently result in drowning.
• Pregnant women take note! Soaking in water above 102°F
(38.5°C)cancausefetaldamageduringtherstthree(3)months
of pregnancy (which could result in the birth of a brain-damaged or
deformed child). If pregnant women are going to use a spa or hot
tub, they should make sure the water temperature is below 100°F
(38°C) maximum.
• The water temperature should always be checked with an ac-
curate thermometer before entering a spa or hot tub. Temperature
controls may vary by as much as 1F°/1C°.
• Persons with a medical history of heart disease, diabetes, cir-
culatory or blood pressure problems should consult their physician
before using a hot tub or spa.
• Persons taking any medication which induces drowsiness
(e.g., tranquilizers, antihistamines, or anticoagulants) should not
use spas or hot tubs.
• Prolonged immersion in hot water can induce hyperthermia.
• Hyperthermia occurs when the internal body temperature
reaches a level several degrees above the normal body tem-
perature of 98.6°F (37°C). Symptoms include dizziness, fainting,
drowsiness, lethargy, and an increase in the internal body tempera-
ture. The effects of hyperthermia include:
• Lack of awareness of impending hazard
• Failure to perceive heat
• Failure to recognize need to leave spa
• Physical inability to leave spa
• Fetal damage in pregnant women
• Unconsciousness resulting in a danger of drowning
2.4 General Operation Description
The blower draws air and fuel through specially designed
orices, delivering a precise mixture to the burner,
located inside the sealed combustion chamber. Water
ows through the heat exchanger, which surrounds
the burner transferring the heat to the water. Exhaust
gases are then directed through a duct where it is vented
to the atmosphere.
