Page 35
ENGLISH
Jandy
®
, JXi
™
Gas-Fired Pool & Spa Heater
|
Installation & Operation Manual
9.5 Operating the Controller
Unless the heater is connected to a remote controller,
all operations are set up and programmed through the
control panel on the top of the heater. See Figure 23.
NOTE: The display light reverts to OFF after two minutes of inactiv-
ity since the last key was pressed.
SPA
MENU
POOL
GAS HEATER IS OFF
PRESS POOL OR SPA
Figure 23. Main Control Panel
9.5.1 Setting up Heater Options
Before using the heater for the rst time, set up the
following options:
• Languages: Set a display language
• Temperature Scale: Set temperatures to be displayed
in either Celsius or Fahrenheit scale
• Display Light Timeout: Set the display light to turn
off after a specic interval of inactivity
To Program the Display Language
MENU
Heater must be in OFF mode to begin
Hold for 5 Seconds
or
SELECT USER
SETUP LANGUAGE
SELECT LANGUAGE
ENGLISH
MENU
or
To Change Language
MENU
To Save
POOL
SPA
or
To Exit
To Program the Temperature Scale (F or C)
MENU
Heater must be in OFF mode to begin.
Hold for 5 Seconds
or
SELECT USER
SETUP TEMPERATURE SCALE
SELECT TEMP SCALE
°F
MENU
or
to Toggle °F and °C
MENU
To Save
POOL
SPA
or To Exit
To Program Display Light to Turn Off Automatically
MENU
Heater must be in OFF mode to begin
Hold for 5 Seconds.
or
SELECT USER
SETUP DISPLAY LIGHT
SELECT DISPLAY LIGHT
2 MIN TIMEOUT
MENU
or
to Toggle:
MENU
To Save
POOL
SPA
or To Exit
To Next Page
