NT–2000 REF Manual
Control Panel Functions
2-4
2. Control Panel Functions (
continued – 4/10
)
⑨ Enter Key
･ When a NAVTEX message is currently being displayed, pressing this key
displays the newest message (e.g. 200/200).
･ When a menu is currently being displayed, pressing this key:
- completes the selection of a desired option,
- executes the function selected or,
- finalizes the current setting.
⑩ Down Key
･ When a NAVTEX message is currently being displayed, pressing this key scrolls
the message screen upward one line at a time, allowing you to view message lines
hidden beyond the lower limit of the screen. When the oldest message (e.g. 1/200)
is displayed, further keypress returns you to the newest message (e.g. 200/200).
Holding down the key accelerates the scrolling.
･ When a menu is currently being displayed, pressing this key selects (highlights)
vertically listed options downward. Be sure to press
after highlighting the
desired option.
⑪ Message/Station Selection Key
–
1/2
･ When a NAVTEX message is currently being displayed, pressing this key
displays a summary list of the transmitter IDs and message types selected for
reception on both the first and second receivers, as in the example below.
Figure 2-5 List of Currently Selected Stations and Message Types – Example
All transmitters and most of
major message types are initially
selected so that the equipment
will receive those selected types
of messages from all stations in
the coverage area.
A particular station or a
particular message type can be
rejected via the menu system.
→ SYSTEM MENU →
5:MAKE SEL/REJ SETTING →
1/2/3 → 1/2 →
Detailed instructions are given in
paragraph 4.8.
To turn off the above lists, press
.
(
continued on next page
)
SELECTED STATIONS:
A B
C D E F G H I J K L M
N O P Q R S T U
V W X Y Z
SELECTED MESSAGES:
A B C D
E F H J K L
V
Z
< FIRST RECEIVER >
SELECTED STATIONS:
A B C D E F G
H I J K L M
N O P Q R S T U V W X Y Z
SELECTED MESSAGES:
A B C D E F H J K L
V Z
< SECOND RECEIVER 1 >
