Johnson Controls CIW01 User Manual

P5415479
35
8.18.3 Temperature Unit
(1) Select “Screen Display Setting” from the
“Menu” screen and press “OK”.
(2) The “Screen Display Setting” screen is
displayed. Select “Temperature Unit” using
“
” or “ ” and press “OK”.
The temperature setting screen is displayed.
(3) The temperature setting options are
displayed. Press “
” or “ ” and select the
setting item.
The temperature setting changes as follows.
“Temperature Unit” ↔ “Temperature Width”
Screen Display Setting
Main/Sub Display
Temperature Unit
Language Setting
Display Adjustment
Entr Rtrn
Sel.
Back
OK
OK
Menu
Back/Help
OK
Menu
Back/Help
OK
Menu
Back/Help
OK
Menu
Back/Help
OK
Menu
Back/Help
OK
Menu
Back/Help
(4) Press “ ” or “ ” and select setting data.
• If “Temperature Unit” is selected
it changes as follows :
“Degrees C” ↔ “Degrees F”.
• If “Temperature Width” is selected
it changes as follows :
“0.5ºC” ↔ “1ºC”
Press “OK” when all settings are
complete.
When the selected language is English,
Fahrenheit temperature degrees can be
selected.
(5) The setting confi rmation screen is displayed.
Select “Yes” using “
” or “ ” and press “OK”
to confi rm the setting.
The screen returns to normal mode.







OK
Menu
Back/Help
OK
Menu
Back/Help
OK
Menu
Back/Help
OK
Menu
Back/Help
