RWB II ROTARY SCREW COMPRESSOR UNITS
INSTALLATION
070.200-IOM (DEC 11)
Page 4
Geometrical
Rotor Max Swept Volume
Compressor Diameter Rotor Speed Drive Shaft End cfm m³/h
Model mm L/D rpm ft³/ Rev m³/Rev 3550 rpm 2950 rpm
TDSH 163S 163 1.35 4500 0.10069 0.002849 357 504
TDSH 163L 163 1.7 4500 0.12679 0.003588 450 635
TDSH/TDSL 193S 193 1.35 4500 0.16653 0.004713 591 834
TDSH/TDSL 193L 193 1.8 4500 0.22204 0.006284 788 1112
TDSH/TDSL 233S 233 1.35 4500 0.29301 0.008292 1040 1468
TDSH/TDSL 233L 233 1.7 4500 0.36897 0.010442 1310 1848
TDSH 233XL 233 2.1 4500 0.45580 0.012899 1618 2283
TDSH/TDSL 283S 283 1.35 4200 0.52501 0.014858 1864 2630
TDSH/TDSL 283L 283 1.7 4200 0.66115 0.018711 2347 3312
TDSH 283SX 283 2.1 4200 0.79546 0.022512 2824 3985
TDSH/B 355S 355 1.1 4200 0.89858 0.025430 3190 4501
TDSH/B 355L 355 1.5 4200 1.12154 0.031739 3981 5618
TDSH/B 355XL 355 1.9 4200 1.42748 0.040398 5068 7150
TDSB355U 355 2.4 4200 1.80328 0.051033 6402 9033
GEOMETRICAL SWEPT VOLUME TABLE
