RWB II PLUS ROTARY SCREW COMPRESSOR UNITS
FORMS
070.200-IOM (DEC 11)
Page 56
Page2 UnitSerial#_____________________________  FrickOrderNo:____________________________
Mode __________________ Capacity Control Setpoints Mode __________________
Setpoint ________ Regulation Safeties Setpoint ________ Regulation Safeties
 High Low LoadInhibit________ High Low LoadInhibit_________
Prop.Band ________ ________  ForceUnload________ Prop.Band _______  ________ ForceUnload_________
DeadBand ________ ________  Warning__________ DeadBand _______ ________ Warning___________
CycleTime ____ Sec _____ Sec WarningDelay___ Sec CycleTime ____Sec ____ Sec WarningDelay____ Sec
VFDPropBand ________ ________  Shutdown_________ VFDPropBand _______ ________ Shutdown__________
VFDInteg.Time____ Sec _____ Sec ShutdownDelay___ Sec VFDInteg.Time____Sec ____ Sec ShutdownDelay____ Sec
 Channel ________________________ Channel _________________________ 
 AutoCycle LowSuction AutoCycle LowSuction
Start  ________ LoadInhibit __________ Start _________ LoadInhibit __________
StartDelay ____ Min ForceUnload __________ StartDelay _____ Min ForceUnload __________
Stop  ________ Warning __________ Stop _________ Warning __________
StopDelay  ____ Min WarningDelay ______ Sec StopDelay _____ Min WarningDelay ______ Sec
 Shutdown __________ Shutdown __________
 ShutdownDelay ______ Sec ShutdownDelay ______ Sec
Compressor Safeties
High Discharge Temperature High Suction Pressure
 LoadInhibit_______   LoadInhibit_______ PSIG
 ForceUnload_______   ForceUnload_______ PSIG
 Warning_______  StartDifferential Warning_______ PSIG
 WarningDelay_______Sec PressureBelow WarningDelay_______ Sec
 Shutdown_______  ________ PSI Shutdown_______ PSIG
 ShutdownDelay_______Sec  ShutdownDelay_______ Sec
HighDischargePressure DualMode _______________ Economizer ________________
RegulationModes1&3Modes2&4 OnWhenAbove_______%
LoadInhibit _____PSIG _____PSIG OffWhenBelow_______%
ForceUnload _____PSIG _____PSIG OverrideDischargePressure________ 
Warning _____PSIG _____PSIG PortValue________
WarningDelay _____Sec _____Sec PressureInput_________________ 
Shutdown _____PSIG _____PSIG FixedPressureSetpoint_________________ 
ShutdownDelay _____Sec _____Sec
 MaximumDischargePressure  ______________PSIG
 HighestCap.ToPermitStart  ______________ % BalancePiston
 StartPeriodBeforeCap.Increase  ______________ On  ____ %
 StoppingPeriodForCap.Unload  ______________ Off  ____ %
 CompressorAutoModeMin.Cap.  ______________ % IgnoreDelay  ____ Min
 CapacityUnloadAssist.  ______________ Rate __________% FailDelay  ____ Min
 SeparatorVelocityRef.  ______________ OilLog_______________ Delay______ Sec.
 CompressionRatio  ______________
 LiquidSlugWarning  ______________ MainOilInjectionOnWhenDischargeTemperature
 LiquidSlugShutdown  ______________ IsAbove__________ °Ffor _____ Sec
Package Safeties
LowCompressorOilTemperature PullDown______________________
 Warning __________Delay_____  Sec CapacityPosition________ %
 Shutdown __________ Delay______  Sec AmountofTime_________Sec
HighCompressorOilTemperature PumpDown____________________
 Warning  ______ Delay_______ Sec OnWhenSuctionAbove____ PSIGDelay_____ Min
 Shutdown  ______ Delay_______ Sec DXCircuit
LowCompressorOilPressure #1Action_______________________
 Warning  ________ PSI Delay________ Sec OffWhenBelow _______ %
 Shutdown  ________ PSI Delay________ Sec OnWhenAbove _______ %
HighFilterPressure #2Action ______________________ 
 Warning  ________ PSI Delay________ Min OffWhenBelow_________ %
 Shutdown  ________ PSI Delay________ Min OnWhenAbove_________ %
MainOilInjection________________________ LiquidInjection__________________
 Shutdown  ________ PSI Delay________ Sec OnWhenAbove __________ Delay_______ Sec
 OilHeaterOffAbove ________ DualPortTransition________
 HighLevelShutdownDelay ________ Sec
 LowOilLevelDelay ________ Sec HotGasBypass_________ %
 OilPumpLubeTimeBeforeStarting________ Sec PowerAssist__________ Sec
 DualPumpTransitionTime ________ Sec
