RWB II PLUS ROTARY SCREW COMPRESSOR UNITS
FORMS
070.200-IOM (DEC 11)
Page 57
Page3 UnitSerial#_____________________________  FrickOrderNo:____________________________
Compressor Motor Setpoints and Information
Motor Name Plate VFD Manufacturer ___________
 MotorAmps___________ MaximumDriveOutput___ %   FrameSize______________
 Volts___________ MinimumDriveOutput___ %   H.P.____________________
 ServiceFactor___________ RemoteControl RPM___________________
 Horsepower___________ RateOfIncrease________ % Delay____  Sec Serial#_________________
 CTFactor___________ RateOfDecrease_______ % Delay____  Sec ServiceFactor___________
RecycleDelay__________ Min CapacityControl  Voltage_________________
HighMotorAmps WhenSlideValveReaches ________ % Hz_____________________
 LoadInhibit______________ DriveSpeedReaches________ % Design_________________
 ForceUnload__________ VariableSpeedMin.SlideValvePosition__________ % Code___________________
 Warning________Delay___Sec SkipFrequencyBands BearingType________________
 Shutdown________Delay___Sec Bottom Top MotorCoupling _____________
  _______ ______
LowMotorAmps  _______ ______
ShutDown________ Delay______ Sec  _______ ______
ConrmedRunningMotorAmps_______  _______ ______
StartingMotorAmpsIgnorePeriod________Sec  _______ ______
Vyper Coolant Setpoints
VyperStandbyTime______ VyperCoolantLowTemp.Alarm______ Delay______ Shutdown______ Delay________
 HighTemp.Alarm______ Delay______ Shutdown______ Delay________
PHD Monitoring Setpoints Condenser Control
Compressor Bearing ____________ Condenser Control Setpoint _____________
Suction End Delay Discharge End Delay Digital Controls Step Order
HighWarning______ gF_____ Sec HighWarning _____ gF_____ Sec ModuleA ________
HighShutdown____ gF_____ Sec HighShutdown____ gF_____ Sec ModuleB ________
 ModuleC ________
MotorBearing______________ ModuleD ________
ShaftSide Delay OppositeShaftSide Delay StepUpDeadBand _________PSI
HighWarning_______ F_____ Sec HighWarning______ F_____ Sec StepUpDelay ________ Sec
HighShutdown_____ F_____ Sec HighShutdown_____ F_____ Sec StepDownDeadBand _________PSI
 StepDownDelay ________ Sec
MotorStator__________________ HighPressureOverride _________PSI
 HighPressureOverrideDelay_____ Sec
Stator1 Delay Stator2 Delay
HighWarning______F ______ Sec HighWarning_____F ______ Sec AnalogControls AnalogOutputA___________
HighShutdown____F ______ Sec HighShutdown____F ______ Sec  AnalogOutputB___________
 ProportionalBand________PSI
Stator3 Delay IntegrationTime_______ Sec
HighWarning______F ______ Sec HighLimit________PSI
HighShutdown____F ______ Sec LowLimit_______ Sec
Miscellaneous
RemoteCapacityDeadband_______ % MaxSlideValveTimer_______ 1/10Sec
HighCompressorOilPressure________________ MaxDischargePressure___________PSI
Shutdown_____PSI Delay____ Sec MaxDischargeandOilTemp ________°F
P&ID Setpoints
Name _________________ __________ _________________ __________
Control ____________ ____________ ____________ ____________
Action _________________ ____________ __________________ ____________
ControlPoint __________________ ____________ __________________ ____________
DeviceSource _____________ __________ ______________ __________
DeviceChannel ____________ ____________ ____________ ____________
Setpoint ____________ ____________ ____________ ____________
DeadBand ____________ ____________ ____________ ____________
Prop.Band ____________ ____________ ____________ ____________
IntegralGain ____________ ____________ ____________ ____________
