Johnson Controls IFC-1010 User Manual

10
Hardware Installation—Installing the IFC-1010/2020
Prerecorded or live voice alarm messages can be dispatched through an
audio message generator. A fire fighters master telephone unit allows
communication between the control panel and fire fighters telephones
installed throughout the system.
Audio power is provided by several sizes of audio amplifiers for use in
voice alarm applications.
An IFC-1010/2020 system can support remotely mounted video display
units, printers, and serial annunciators.
IFC-2020 maximum addressable device capacity (ten LIB-200 modules):
990 Intelligent photoelectric, ionization, and thermal (heat) detectors.
+ 990 Addressable pull stations, monitor modules, control modules, and XP Transponder
circuits
= 1980 Addressable Devices system wide.
IFC-1010 maximum addressable device capacity (four LIB-200 modules):
396 Intelligent photoelectric, ionization, and thermal (heat) detectors.
+ 396 Addressable pull stations, monitor modules, control modules, and XP Transponder
circuits
= 792 Addressable Devices system wide.
The following are general terms and their associated specific part numbers
in this manual:
• PRN PRN-4
• CRT CRT-2
Voice
Evacuation
Functions
Audio Amplifier
Power
Peripherals
IFC-2020
Maximum
Addressable
Device Capacity
(ten LIB-200
modules)
IFC-1010
Maximum
Addressable
Device Capacity
(four LIB-200
modules)
