Hardware Installation—Installing the IFC-1010/2020
129
All LIBs are power-limited. If the wiring connected to the LIB-200 leaves
the building it must be in conduit. It can not exceed 1,000 meters
(10,000 feet), must not cross any power lines, and must not be in the
vicinity of any high voltage. These outdoor wiring restrictions do not apply
to the LIB-200A or the LIB-400. Refer to Figure 92 and Figure 93.
Table 12 is a minimal configuration for a NIB-96 with base address=01
and may be used when programming the NIB-96. For further information,
refer to the NIB-96 Network Interface Board Technical Bulletin
(LIT-445101).
Table 12: NIB-96 (Minimal Configuration)
Master
Software
Type
Master
SLC
Address
Slave
Annunciator
Address
Slave
Software
Type ID
Function
MON
L1M1 A6P1 AAST General Trouble
not used
not used A6P2 AMON not used
CON
L1M3 A6P3 ARST Slave Reset
not used
not used A6P4 AMON not used
SARM
L1M5 A6P5 AMON Security Alarm
(typical)
SSYM
L1M6 A6P6 AMON Security Tamper
(typical)
NOA
L1M7 A6P7 AMON Non-Alarm Input
(typical)
CON
L1M8 A6P8 ACON Control Output
(typical)
NFPA 72-1999
Proprietary Fire
Alarm Systems
Fire Alarm,
Security Alarm,
and Trouble
Signal
Transmission
