Johnson Controls IFC-1010 User Manual

130
Hardware Installation—Installing the IFC-1010/2020
1
2
3
4
5
6
1
2
3
4
5
6
7
8
P3P2
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
P3
P5
1
2
3
4
5
6
P2
SLC Loop
OUT
SLC Loop IN
(From Master FACP
LIB at Central Station)
EIA-485 Loop OUT
To additional EIA-485
devices if Installed.
SIB-2048 or SIB-N2
in Protected Premises
Control Unit (Slave)
NIB-96
No Connection
on P2 or P3 if ICA-4L
chassis is used.
INTELLEGENT FIRE DETECTOR AND ALARM SYSTEMS
TM
LIB-200,
LIB-200A,
or LIB-400
TM
TOR AND ALARM SYSTEMS
SIB-2048A
or
SIB-NET
NIB-96
IFC-1010/2020
Central Station
(Master)
IFC-1010/2020
Protected Premises Control Unit
(Remote)
Terminal 5 (+)
Terminal 6 (-)
EIA-485 Loop IN
propfire
Terminal Assignments
SLC Loop IN:
SLC Loop OUT:
From: Master LIB-200, LIB-200A, or LIB-400
P2 Terminals 1 (+) and 3 (-)
To: NIB -9 6
P5 Terminals 1 (+) and 3 (-)
From: NIB-96
P5 Terminals 5 (+) and 7 (-)
To: Next device on SLC Loop
From: SIB
P5 Terminals 5 (+) and 6 (-)
To: NIB -9 6
P4 Terminals 5 (+) and 3 (-)
From: NIB-96
P5 Terminals 6 (+) and 4 (-)
To: Next device on EIA-485 Loop
EIA-485 Loop IN:
EIA-485 Loop OUT:
Notes:
This arrangement can be employed for
Central Station and Proprietary (NFPA 72)
service.
This application is not suitable for separate
transmission of sprinkler supervisory
conditions.
During programming, NFPA menu option
“72D” must be chosen.
Figure 92: Proprietary Fire Alarm Systems
