Johnson Controls IFC-1010 User Manual

Hardware Installation—Installing the IFC-1010/2020
121
The EIA-485 Reference (P5-1) for the SIB must be connected to any ACS
device that is not within the same cabinet. Connect P5-1 of the SIB to:
• AMG-1 at P3-1, P3-2
• ACM-16AT at TB1-4
• LDM-32 at TB1-4
• NIB-96/AMG-1 power supply remote from the SIB (MPS-24A at
TB2-2)
• SCS-8/L at TB1-4
• LCD-80 at P1-4
• RPT-485W Reference A at TB1-5
• RPT-485W Reference B at TB2-5
• RPT-485 WF Reference A at TB1-5
