109Modul-AIR Exhaust Air Heat Pump Installation Guide
Modul-AIR All-E Sound Data
Flow Rate 160m
3
/h Compressor Off
Hz 63 125 250 500 1k 2k 4k 8k WEIGHTED
Breakout (dB)
Modul-AIR - 48.1 44.7 48.3 46.7 42.8 39.6 35.1 32.9 48.5
Induct
Modul-AIR Extract 59.2 69.4 63.7 52.3 38.6 34.3 30.6 27.7 57
Modul-AIR Exhaust 68.6 68.3 67.6 61.7 55.5 51.6 49.5 47.9 63.5
Flow Rate 200m
3
/h Compressor Off
Hz 63 125 250 500 1k 2k 4k 8k WEIGHTED
Breakout (dB)
Modul-AIR - 52 45.4 50.1 47.2 42.9 40.1 36.2 35.1 49
Induct
Modul-AIR Extract 59.9 69.9 64 54 41.4 36.5 33.9 32.3 57.5
Modul-AIR Exhaust 68.9 68.8 72.2 64.3 57.8 53.7 52 50.5 67
Flow Rate 200m
3
/h Compressor Off
Hz 63 125 250 500 1k 2k 4k 8k WEIGHTED
Breakout (dB)
Modul-AIR - 63.4 50.8 49.7 46.9 45.8 43.4 37.7 33.5 50.5
Induct
Modul-AIR Extract 71.6 67.7 65.4 52.3 38.2 34.2 30.2 32.7 57
Modul-AIR Exhaust 70 69.3 67. 3 60.8 53.8 49.2 45.6 43.4 62.5
