25Modul-AIR Exhaust Air Heat Pump Installation Guide
Installation Location
Restrictions around the Modul-AIR Heat Pump
Certain clearance distances must be adhered to prior to citing an area for installing the unit. Clearance is
required to provide sufficient space for installation and maintenance.
Minimum Required space around the Modul-AIR Unit
a min. 300mm
b min. 500mm
c min. 100mm
d min. 10mm (when using the top connection for incoming ventilation air).
min. 500mm (when using the side connection for incoming ventilation air).
e min. 10mm
