Green Comfort Main PCB Board
The internal electrical connection layout of the Green Comfort is shown above.
P SENSOR AIRFLOW
EXT. BUS RJ45
USB COM PORT
T AIR-IN
M
230 Va c
L
N
GND
Tach
PWM+
T AIR-OUT
FAN
M
MODULATING VALVE ACTUATOR
N
230 Vac L - CLOS E
230 Vac L - OPEN
L
N
1L + N + PE 16 A B-TYPE
230 Vac 50 Hz POWER SUPPLY
PE
RIBBON CABLE
EXT. CONNECTIONS
250 mA/M FUSE FOR
MODULATING VALVE
ACTUATOR
