Maintenance of the Modul-AIR and Spare Parts
This chapter describes the simplest maintenance work on the Modul-AIR Unit itself.
ONLY the replacement of the filter may be done by the user themselves, any other work on the Modul-AIR
heat pump must be completed by a technician specially trained by Joule.
Always replace parts of the Modul-AIR with original Modul-AIR parts from Joule. The use of third-party parts
may cause the product to malfunction or create a hazard. Disregarding of these points may have a negative
effect on the Modul-AIR warranty and void Joules statutory responsibilities.
Spare parts list
The design and operation of an exhaust air heat pump system has a direct link to its output and efficiency.
Consideration should be given to heating and ventilation at an early stage in any project as the system
requires to be integrated with construction and building project process.
A Modul-AIR housing E Electric backup heater* I Front cover
B Three-way valve* F Fan box J Front plate
C Central Heating Pump G Drip tray K Air Filter
D Touch display H Control Unit L Filter cap
* - These parts are only present in the All-E variant of the Mould-AIR unit.
