45Modul-AIR Exhaust Air Heat Pump Installation Guide
Connecting the Green Comfort
Modul-AIR All-E & Green Comfort – Righthand side
Modul-AIR All-E & Green Comfort – Lehand side
Green
Comfort Flow
Green Comfort Return
Drain
DHW Tank Flow
Space Heating Flow
Common
System Return
Space Heating Flow
DHW Tank Flow
Green
Comfort Return
Drain
Green
Comfort Flow
Common
System Return
