Power Specification
Modul-AIR Electrical Connections
Unit HZ Volts Phase Starting Current Mains Fuse
Joule Modul-AIR Aqua 50 230 Single 10 Amp 16 Amp
Joule Modul-AIR All-E 50 230 Single 10 Amp 32 Amp
Green Comfort 50 230 Single 10 Amp 16 Amp
Modul-AIR - Cable Specifications
Unit Mains Power 3 Core Flex, 6mm2, 1 meter Fly Lead x1 Supplied
Tank Sensor 2 Core, 0.25-0.50mm2, 2 meter x2 Supplied
Immersion Power 3 Core, 1.5mm2 x1 Not supplied
Room Thermostats 2 Core, 0.75mm2 OT x1 Not supplied
RF Receiver (Optional) 3 Core, 0.5mm2 x2 Not supplied
Green Comfort - Cable Specifications
Unit Mains Power 3 Core Flex, 6mm2, 1 meter Fly Lead x1 Supplied
UTP Comms cable UTP Data cable, 3 meter x1 Supplied
• The Heat Pump MUST be connected to the mains through a suitably sized RCBO.
• The power cable is pre-wired to the Exhaust Air Heat Pump.
• This Equipment complies with IEC 61000-3-12.
• If extension of the power cable is required, use the grade H05V2V2-F or equivalent materials.
• Ensure that main supply connection is made through a switch that disconnects all poles, with contact
gap of a least 3 mm.
• Devices disconnected from the power supply should be completely disconnected in the condition of
overvoltage category.
• Keep distances of 20mm or more between power cable and communication cables.
During the unit installation first install the ventilation connections, then the piping
connections and then finally the electrical connections.
If the unit is being uninstalled disconnect it in a reverse procedure to the above
