Connect cords in the following order.
5) Insert yellow/green earth cord
1
coming from
the machine head inside the electrical box
through front cover through hole B, and pass it
through cord clamp “b” as illustrated and tighten
it with screw at the position
2
in the illustration.
6) Insert white square connector 9P black cord
3
coming from the machine head inside the electri
-
cal box through front cover through hole B, and
insert it into connector CN38
4
of the circuit
board attached to the front cover.
7) Insert white connector 4P black cord
5
coming
from the machine head inside the electrical box
through front cover through hole B, and insert it
into connector CN21
6
of the circuit board at-
tached to the front cover.
8) Insert white connector 26P cord
7
coming
from the operation panel inside the electrical
box through front cover through hole B, pass it
through cord clamps “b”, “c” and “d”, insert it into
connector CN34
8
, and lock it.
2
b
B
1
3
B
4
5
6
(2) Connecting the connectors
• Each connector has the inserting direction. Check the direction and securely insert it. (In
case of the type with lock, insert up to the lock.)
• If the connector is forcibly inserted, trouble or accident will be caused.
• Never pull out the connectors inserted at the time of delivery.
• The sewing machine fails to work if the connectors are not properly inserted. Not only the
problem such as the error warning or the like but also breakage of the sewing machine or
electrical box will occur.
B
u
i
c
b
d
B
To Next Page
