JUKI IT-100D - Setting of the Sewing Shape; 2-Step ZGzag, 3-Step ZGzag and 4-Step ZGzag StTch

– 37 –
Setting of the zigzag
width
Change the zigzag width
with +/– of switch
4
.
Setting of the position
of stitch base line
Change the position of
stitch base line with +/– of
switch
5
.
• Zigzag width can be set from “0” to 10 mm. (Set value is limited by the max.zigzag width limitation.)
• Stitch base line can be set as follows. When the center of zigzag is “0.0”, Right side : “+” Left side : “–”.
6-6. Setting of the sewing shape
Setting of the position of sewing start
Set the position of sewing start with
▲／▼
of switch
6
.
Setting of the stop position
Set the stop position with
▲／▼
of switch
7
.
(1) 2-step zigzag, 3-step zigzag and 4-step zigzag stitch
■
Sewing shape list rst screen
1) Select 2-step (3-step or 4-step) zigzag stitch in the sewing shape list rst screen.
2) The selected shape reverses and is displayed on the left end of the screen.
3) Press to display the sewing shape setting screen.
■
Sewing shape setting screen
2-step zigzag
3-step zigzag
4-step zigzag
Stop position, optional Stop position, right Stop position, left
Sewing start Optional Sewing start Right Sewing start, left
4
4
5
5
6
6
7
7
