(3) Communication mode
The matters below can be performed in the communication mode.
1) Sewing machine data server utility (hereafter : SU-1) or vector form (VDT) data from media can be regis-
tered to non-registered No. of custom pattern.
2) Custom pattern can be changed to the vector form and be uploaded to SU-1 or the media.
3) Parameter data (EPD) can be overwritten and registered to the condensation custom pattern from SU-1
or the media.
4) Condensation custom pattern can be uploaded to SU-1 or the media.
* For setting of the communication with SU-1, refer to the Instruction Manual for SU-1.
[Maintenance personnel level]
1) Turn ON the power. When the needle bar is not in the UP position, turn the handwheel to bring the needle
bar to its UP position.
2) Press switch
1
for approximately three seconds to display the information screen.
2
: Ver display .......................................For the details, refer to the Engineer’s Manual.
3
: Sewing common data
4
: Function setting
................................Refer to 6-16 Function setting procedure.
5
: Sewing management information
6
: Communication mode
7
: Date and time setting .......................For the details, refer to the Engineer’s Manual.
8
: Screen No.2
■
Information screen (Maintenance personnel level)
q
!2!1!0
9
i
uytrew
9
: Hook adjusting mode .......................Refer to 8-6. Hook adjusting mode.
!0
: USB thumb drive format
...................For the details, refer to the Engineer’s Manual.
!1
: Network setting ................................For the details, refer to the Engineer’s Manual.
!2
: Panel setting ....................................Refer to 6-19. Panel memory switch setting.
* When you execute formatting of the USB thumb drive, all pieces of data stored on it are erased. Do not
format the USB thumb drive in any case other than initialization of the medium.
■
Information screen No. 2 (Maintenance personnel level)
