JUKI IT-100D - Installing the Electrical Box; Connecting the Power Switch Cord (Japan and General Export Area); Installing the Operation Panel (IT-100 D)

– 6 –
4-6. Connecting the power switch cord (Japan and general export area)
1) Loosen screw
1
located on the side of the power
switch supplied as accessories and remove the
power switch cover.
2) Connecting the input power cord of electrical box
¡
When the input power cord of electrical box is 4P
Put 4P cord from hole A of the power switch and
securely x green/yellow cord to
5
, white cord to
2
,
black cord to
3
and red cord to
4
with screws.
¡
When the input power cord of electrical box is 3P
Put 3P cord from hole A of the power switch and
securely x green/yellow cord to
5
, brown cord to
2
and sky blue cord to
3
with screws.
3) Connecting the power cable supplied as accessories
¡
In case of 3-phase power cable
Put power cable from hole B of the power switch, and
securely x green/yellow cord to
9
, white cord to
6
,
black cord to
7
and red cord to
8
with screws.
¡
In case of single phase power cable
Put power cable from hole B of the power switch,
and securely x green/yellow cord to
9
and other
cords to
6
and
7
with screws.
8
is not used.
4) Installing the power switch cover
Securely tighten screw
1
located on the side of
the power switch.
4-7. Installing the operation panel (IT-100D)
1) Install operation panel
1
on the machine head
using screws
3
which have been assembled to
panel installing bracket
2
.
4-5. Installing the electrical box
Install the electrical box on the under side of the
table using round-head bolts
1
, plain washers
2
,
spring washers
3
and nuts
4
supplied with the ma
-
chine at the location illustrated, and using bolt having
hexagonal indentation on the head
5
, spring washer
6
and plain washer
7
supplied with the machine at
the location illustrated.
Do not disassemble the operation
panel to prevent it from breakage.
1
6
9
B
7
8
3
4
5
2
1
2
5
4
3
6
7
A
1
2
3
3
3
