11–1. Error code list (Error display in panel)
There are the following error codes in this device. These error codes interlock (or limit function) and inform
the problem so that the problem is not enlarged when any problem is discovered. When you request our ser-
vice, please conrm the error codes.
No. Description of error detected Cause Item to be checked or corrective measure
Mirror LED ash
Pictograph display
– UP position detection error when
turning ON the power
• When needle position is not UP position at the
time of turning ON the power.
• Set to UP position by turning handwheel by hand.
• Connect synchronizer connector.
–
003 Disconnection of synchronizer
connector
• When position detection signal is not inputted
from the sewing machine head synchronizer.
• When the synchronizer has broken.
• Check the synchronizer connector (CN30) for
loose connection and disconnection.
• Check whether the synchronizer cord has broken
since the cord is caught in the machine head or
the like.
–
004 Synchronizer lower position sen-
sor failure
005 Synchronizer upper position sen-
sor failure
007 Overload of motor
• When the machine head is locked.
• When sewing extra-heavy material beyond the
guarantee of the machine head.
• When the motor does not run.
• Check whether the thread has been entangled in
the motor pulley.
• Check the motor output connector (4P) for loose
connection and disconnection.
–
008 Machine head connector failure
•
W
hen the machine head connector is not properly
read.
• Check the machine head connector (CN54) for
loose connection and disconnection.
–
011 Media not inserted • Media is not inserted.
• Turn OFF the power.
–
012 Read error • Data read from media is not possible.
• Turn OFF the power.
–
013 Write error • Data write to media is not possible.
• Turn OFF the power.
–
015 Format error • Formatting cannot be performed.
• Turn OFF the power.
–
016 External media capacity over
• Capacity of media is short.
• Turn OFF the power.
–
019 File size over
• File is too big.
• Turn OFF the power.
–
024 Pattern data size over • Number of stitches
and data amount which can
be handled with device are over.
• Turn OFF the power.
–
032 File compatibility error
• There is no le compatibility. • Turn OFF the power.
–
040 Travel limit over • Sewing data has exceeded sewing possible area.
• Turn OFF the power.
–
042 Operation error
• Operation of sewing data cannot be performed. • Turn OFF the power.
–
053 Execution of panel backup data
initialization (Not error)
• When model code of panel does not agree with
that of control box.
When executing initialization operation with the
panel.
• Turn OFF the power.
–
302 Fall detection switch failure
• When fall detection switch is inputted in the state
that the power is turned ON.
•
Check whether the machine head is tilted without
turning OFF the power switch (sewing machine
operation is prohibited for safety sake).
•
Check whether the fall detection switch cord is caught in
the sewing machine or the like and has broken.
• Check whether the fall detection switch lever is
caught in something.
–
490 Pattern setting error of continu-
ous stitching and cycle stitching
•
When pattern No. is not set to continuous stitching.
• When the number of stitches of 1st step of con-
tinuous stitching is "0".
• When pattern No. is not set to cycle stitching.
• Re-enter data after reset operation.
• Set pattern No. and number of stitches.
7 times ash
491
Cycle stitching pattern error • When pattern to be used in cycle stitching be-
comes error.
• Re-enter data after reset operation.
• Correct data of pattern which becomes error.
7 times ash
