– 11 –
■
Installing the connecting rod
1) Move pedal
3
to the right or left as illustrated by
the arrows so that motor control lever
1
and con-
necting rod
2
are straightened.
■
Adjusting the pedal angle
1) The pedal tilt can be freely adjusted by changing
the length of the connecting rod.
2) Loosen adjust screw
4
, and adjust the length of
connecting rod
2
.
When the insertion of the connector is completed,
lock the cord clamps.
q
Take care so that the cord is not caught between
the rear cover and the electrical box main body,
close the rear cover while pressing section A on
the lower side of the rear cover, and tighten four
screws
1
.
w
Press down cord presser plate C of cord through
hole B of the front cover, press the cord, and
tighten screws
2
.
1
2
3
A
B
C
4
3
4
B
A
1
2
Clamp
1
4
3
2
4
Lightly press the corner of clamp.
(Cord clamp is locked with a click.)
How to lock the cord clamp
4-9. Attaching the connecting rod
1) Fix connecting rod
1
to installing hole
B
of pedal
lever
2
with nut
3
.
2) Installing connecting rod
1
to installing hole
A
will lengthen the pedal depressing stroke, and the
pedal operation at a medium speed will be easier.
4-10. Adjustment of the pedal
