JUKI IT-100D - NAME of each Component

– 1 –
1. NAME oF EACH CoMPoNENT
1
Needle thread draw-out device (LZ-2290A(U)-7)
2
Wiper switch (WB,CB type)
3
Thread take-up cover
4
Finger guard
5
Thread tension controller (Rotary tension)
6
Electrical box
7
Pedal
8
Knee lifter lever
9
Power switch
4
3
2
!4
!3
!5
!6
!2
!1
!7
o
q
t
!0
i
y
u
!8
!0
Hand switch
!1
Stitch length dial
!2
Condensation dial
!3
Operation panel
!4
Bobbin winder
!5
Tension controller No. 1 (Pre-tension)
!6
Thread stand
!7
Oil supply opening
!8
Mirror inversion switch
