When the Auto-lifter (AK121) is used :
14) Insert white connector 2P cord
@
1
coming from
the machine head inside the electrical box
through front cover through hole B, pass it
through cord clamps “a”, “e” and “f”, and insert it
into connector CN40
@2
.
When the bird’s nest prevention device is used
(CB type)
15) Insert white small connector 6P cord
@3
com-
ing from the machine head inside the electrical
box through front cover through hole B, pass
it through cord clamps “a” and “e”, and insert it
into connector CN52
@4
.
When foot pedal for standing work (PK70 or 71) is
used :
16) Insert black connector 12P cord
@5
inside the
electrical box through front cover through hole
B coming from the foot pedal for standing work,
pass it through cord clamps “b” and “c”, and
insert it into connector CN32
@6
.
17) Connect white connector 2P of cord
@7
sup-
plied as accessories to which red connector 2P
and white connector 2P are attached to white
connector 2P
@8
of under cover of the machine
head.
Fix omega lock
@9
supplied as accessories with
the neighboring cords and cord
@7
as shown in
the gure.
18) Insert red connector 2P side of cord
@7
supplied
as accessories to which red connector 2P and
white connector 2P are attached inside the elec
-
trical box through front cover through hole, and
insert it into red connector CN25
#0
.
@1
@2
@4
@3
@6
@5
f
e
a
a
e
b
c
@8
@7
@9
#0
@7
Change the setting of function setting No.
23 from “0” to “1” after completing all set-up
procedure. For the details, see p.78 and p.81.
