– 45 –
3) Set 2-point condensation width adjustment with the second screen. (Width can be narrowed up to max.
–
5 mm.)
7
: Set 2-point condensation width adjustment at the sewing start.
8
: Set 2-point condensation width adjustment at the sewing end.
* 2-point condensation width adjustment can narrow the width from the rst needle entry position to the next
needle entry position when performing the reverse feed stitching. (When set value is “0”, there is no com
-
pensation.)
* When the width adjustment is performed, the width between 2 points can be narrowed and the fray of
thread is lessened.
■
The rst screen of reverse feed stitching setting (2-point condensation)
Press to display the second screen.
Press to display the rst screen.
▲
■
The second screen of reverse feed stitching setting (2-point condensation)
▲
u i
u i
q w e r t y
q w e r t y
