– 8 –
(5) Piping of the air (PLC-2710, 2760, 2760L, 2765)
Connect the air hose coming from the machine head to the position shown above while matching the
number of the air hose and the number of the port.
(AK type) (AK/BT/DL type)
CN151
CN152
CN153
AK (wire mark
)
AK (wire mark
)
(6) Routing the air hose and cable (PLC-2710, 2760, 2760L, 2765)
DL (wire mark
)
BT (wire mark
)
Pass the air hose and cable through air-cable hole
to route them under the table.
To Next Page
