– 21 –
1) Lift latch of hook, and take out the bobbin.
2) Put the bobbin into the shaft in the hook correctly
and release the latch .
1. Do not make the machine run idle with
the bobbin (bobbin thread). The bob-
bin thread is caught in the hook. As a
result, the hook may be damaged.
2. Be careful so as not to get hurt with the
top end of the counter knife.
3. In case of 2-needle machine, the same
procedure is taken for both left and
right hooks.
WARNING :
To protect against possible personal injury due to abrupt start of the machine, be sure to start the
following work after turning the power off and ascertaining that the motor is at rest.
3-7. Attaching and removing the bobbin
PLC-2710, 2760, 2760L
PLC-2710-7, 2760-7
PLC-2765
To Next Page
