1. SPECIFICATIONS
No. Item Application
1 Model PLC-2710 PLC-2760
2 Model name Post-bed, 1-needle, unison-feed,
lockstitch machine with vertical-axis
large Hook
Post-bed, 2-needle, unison-feed,
lockstitch machine with vertical-axis
large Hook
3 Application Medium- to heavy-weight materials, car seat, furniture
4 Sewing speed Max. 2,500 sti/min
(See
"6. SEWING SPEED TABLE" p.43
.)
5 Needle GROZ-BECKERT 135 x 17 (Nm 100 to Nm 180) (Standard : Nm 140)
6 Applicable thread size for
sewing
#30 to #5
7 Applicable thread size to
be cut
8 Stitch length Max. 12 mm (forward/reverse feed)
9 Stitch length dial 1-pitch dial
10 Presser foot lift Hand lifter : 10 mm
Knee lifter : 20 mm
11 Stitch length adjusting
mechanism
By dial
12 Reverse stitch adjusting
method
By lever
13 Thread take-up Link thread take-up
14 Needle bar stroke 40 mm
15 Amount of the alternate
vertical movement
1 mm to 9 mm (Alternate vertical dial adjustment type)
16 Hook Vertical-axis 2-fold hook (Latch type)
17 Feed mechanism Box feed
18 Top and bottom feed
actuation mechanism
Timing belt
19 Thread trimming method
20 Lubrication Automatic lubrication by oil tank (with oil gauge)
21 Lubricating oil JUKI New Defrix Oil No. 1 (equivalent to ISO standard VG7)
or JUKI MACHINE OIL No. 7
22 Bed size 643 mm × 178 mm
23 Space under the arm 347 mm × 298 mm
24 Hand wheel size V-belt effective diameter : ø76.0 mm
Outer diameter : ø140 mm
25 Motor/Control box M51N 750W / SC-922A
26 Machine head weight 76 kg 79 kg
27
Noise -
Equivalent continuous emission
sound pressure level (L
pA
) at the
workstation:
A-weighted value of 79.5 dB;
(Includes K
pA
= 2.5 dB); according to
ISO 10821- C.6.2 - ISO 11204 GR2
at 2,500 sti/min.
-
Equivalent continuous emission
sound pressure level (L
pA
) at the
workstation:
A-weighted value of 84.0 dB;
(Includes K
pA
= 2.5 dB); according to
ISO 10821- C.6.2 - ISO 11204 GR2
at 2,500 sti/min.
-
Sound power level (L
WA
);
A-weighted value of 86.0 dB;
(Includes K
WA
= 2.5 dB); according to
ISO 10821- C.6.2 - ISO 3744 GR2 at
2,500 sti/min.
