– 29 –
(2) When you want to change the tension of the thread take-up spring
(1) When you want to change the stroke of the thread take-up spring
WARNING :
To protect against possible personal injury due to abrupt start of the machine, be sure to start the
following work after turning the power off and ascertaining that the motor is at rest.
4-3. Thread take-up spring
󱀄
󱀃
󱀁
󰿿
PLC-2765
PLC-2710, 2710-7, 2760, 2760-7, 2760L
󱀀
󱀂
󱀀
󱀂
1) Loosen screw
󱀀
. Adjust thread take-up spring
󰿿
by moving it in the slot.
2) Loosen screw
󱀂
. Adjust thread take-up spring
󱀁
by moving thread take-up spring adjusting
plate
󱀃
along thread take-up spring base
󱀄
.
* The PLC-2710 and -2710-7 do not have
thread take-up spring
󱀁
.
󱢳
󱀅
󰿿
󱀁
󱀆
󱀇
PLC-2765
PLC-2710, 2710-7, 2760, 2760-7, 2760L
1) To adjust the tension of thread take-up spring
󰿿
,
loosen nut
󱀅
first. Turn spring shaft
󱀆
coun-
terclockwise
A
to increase the tension or clock-
wise
B
to decrease it. After the adjustment, x
the stud by tightening nut
󱀅
.
2) To change the tension of thread take-up spring
󱀁
, loosen screw
󱀇
rst. Turn nut
󱢳
counter-
clockwise
A
to increase the tension or clock-
wise
B
to decrease it. After the adjustment, x
nut by tightening screw
󱀇
.
* The PLC-2710 and -2710-7 do not have
thread take-up spring
󱀁
.
B
A
B
A
