JUKI RS-1 - Removing the y Ball Screw

To Next Page

To Previous Page

Maintenance Guide

1-47

1-7-2. Removing the Y Ball Screw

(1) Loosen the coupling Y screw.

∗ Be careful not to remove the coupling screw.

●YL

Y_MOTOR

Coupling

Coupling screw
