Maintenance Guide

1-58

[RS-1R]

(9) Insert the bearing in the Y-axis ball screw and fix it with the lock nut.

(10) Attach END_BRACKET to the bearing. (Secure the fixing screws temporarily.)

END_BRACKET

Lock nut

Bearing
