Industrial Sewing Machine SADE
45
NOTE!
The company JUKI CENTRAL EUROPE Sp. z o.o.
responsibility for damage caused during the execution
connection improper with the applicable regulations and subse-
quent operation of the machine.
The machine must be connected to the mains current single phase 1 x 230 V, a set of
plug / socket, by cable which is standard machine equipment.
Before connecting the machine to the mains current check that the switch is in the off
position.
Make sure the line voltage is compatible with the specifications of the machine. If not,
an electrician should introduce appropriate safety devices. Connect the machine to the
power source.
After connecting the machine to the power supply check the correctness of connection
and perform a functional test.
Switch machine rotating the main switch to ON position. Then push the backlit button
“Computer START / STOP”. Wait until the computer system starts. Further details – see
clause 7.2 and 7.3.
In case of any problems, contact the machine manufacturer.
Electrical components diagram – see fig. 23. Control block diagram – see fig. 24.
A person with a valid electrical license must perform electrical check-
ups before the first start, and record the result in a report. These tests
should be repeated periodically.
Performing checking tests with the positive result is a condition of the
To Next Page
