Industrial Sewing Machine SADE
93
7.1.3.5 Others
From this field an additional material such as a plastic retainer etc. for the sewing can
be selected (reference to the material database).
7.1.3.6 Needle wear
By checking the stitch counter active box in the product configuration the needle change
interval time can be set. The needle wear parameter in this screen acts as a counter to
count the stitches since the last needle change.
7.1.3.7 Material combinations
The sewing material part of the product definition editor is used to select acceptable ma-
terial identification codes for the current product. For material different codes can be set
and scanned. If no materials are selected for a certain tab, this material number will not
be checked in the production cycle. Material tabs where codes have been selected are
indicated green.
