Industrial Sewing Machine SADE
80
For an easy selection you can select or deselect the display of material groups.
Simply click on the tab on top, selected material group is highlighted in grey colour.
Fig. 45. Selected parameter group
You can define up to five different sub materials to be used and checked for presence
upon starting the sewing process.
1) Cone top thread
2) Cone bottom thread
3) Needles
4) Sewing material
5) Others (free definition)
Fig. 46. Material tab options
NOTE!
The hand held barcode scanner input is regarded as manual input.
Sewing job profile editor
Click on [sewing jobs] to access the editor (figure 44 in clause 7.1.2.9). The following
screen will appear:
Choose one of the sewing jobs to be edited or add a new one.
