Start temperature
(internal analog
inputs)
Configuration
➔ Analog inputs
➔ Analog input 1 — 12
➔ Start temperature
any value Only for sensor: current,
voltage with linearization,
resistance thermometer,
thermocouple.
Only for signals that have
not yet been linearized.
End temperature
(internal analog
inputs)
Configuration
➔ Analog inputs
➔ Analog input 1 — 12
➔ End temperature
any value Only for sensor: current,
voltage with linearization,
resistance thermometer,
thermocouple.
Only for signals that have
not yet been linearized.
Scaling start
(internal analog
inputs and counters)
Configuration
➔ Analog inputs
➔ Analog input
1—12
Counter 1 — 2
➔ Scaling start
-99999 to 0 to +99999 Only for sensor: current,
voltage with straight-line
linearization, for sensor:
resistance transmitter and
potentiometer, and for
counter inputs.
Scaling end
(internal analog
inputs and counters)
Configuration
➔ Analog inputs
➔ Analog input
1—12
Counter 1 — 2
➔ Scaling end
-99999 to +100 to +99999
(with analog input)
or
-99999 to +10000 to
+99999 (with counters)
Only for sensor: current,
voltage with straight-line
linearization, for sensor:
resistance transmitter and
potentiometer, and for
counter inputs
Filter constant
(internal analog
inputs)
Configuration
➔ Analog inputs
➔ Analog input 1 — 12
➔ Addit’l parameters
➔ Filter constant
0.0 — 0.1 —10.0s
Channel name
(internal analog
inputs and counters)
Configuration
➔ Analog inputs
➔ Analog input
1—12
Counter 1 — 2
➔ Addit’l parameters
➔ Channel
name
7 characters
Inp. x
or
counterx
Short designation. It is
shown in all diagram
representations.
v Chapter 3.8 “Text entry”
Channel
description
(internal analog
inputs and counters)
Configuration
➔ Analog inputs
➔ Analog input
1—12
Counter 1 — 2
➔ Addit’l parameters
➔ Channel
description
2 x 20 characters
Meas. inp. x
or
event counter x
Detailed description. It is
additionally shown in the
two numerical displays.
v Chapter 3.8 “Text entry”
Unit
(internal analog
inputs and counters)
Configuration
➔ Analog inputs
➔ Analog input
1—12
Counter 1 — 2
➔ Addit’l parameters
➔ Unit
5 characters
%
(only with analog input, no
pre-assignment for counter
input)
v Chapter 3.8 “Text entry”
Parameter Value/selection Description
