JUMO LOGOSCREEN - Page 79

79
4 Configuration parameters
Decimal place
(internal analog
inputs and counters)
Configuration
➔ Analog inputs
➔ Analog input
1—12
Counter 1 — 2
➔ Addit’l parameters
➔ Decimal place
Automatic,
X.XXXX,
XX.XXX,
XXX.XX,
XXXX.X, (with analog inp.),
XXXXX.(with counters)
Automatic: representation
with maximum resolution
Integrator
time base
(internal analog
inputs)
Configuration
➔ Analog inputs
➔ Analog input 1 — 12
➔ Addit’l parameters
➔ Integr.
time base
Off,
Second,
Minute,
Hour,
Day
Time base for the
integrator. If the time base
is switched off, the
integrator indication is
suppressed in the report.
v Chapter 2.6 “Integrator”
Integrator unit
(internal analog
inputs)
Configuration
➔ Analog inputs
➔ Analog input 1 — 12
➔ Addit’l parameters
➔ Integr. unit
5 characters v Chapter 2.6 “Integrator”
Sensor
(external
analog inputs and
counters)
Configuration
➔ Analog inputs
➔ External input
1—36
External counter 1—2
➔ Sensor
Off,
Ext. input,
Ext. counter
v Chapter 2.3 “Analog
inputs”
v Chapter 2.5 “Counters”
Scaling start
(external
analog inputs and
counters)
Configuration
➔ Analog inputs
➔ External input
1—36
External counter 1—2
➔ Scaling start
-99999 to 0 to +99999
Scaling end
(external
analog inputs and
counters)
Configuration
➔ Analog inputs
➔ External input
1—36
External counter 1—2
➔ Scaling end
-99999 to +100 to +99999
(with analog input)
or
-99999 to +10000 to
+99999 (with counters)
Channel name
(external
analog inputs and
counters)
Configuration
➔ Analog inputs
➔ External input
1—36
External counter 1—2
➔ Addit’l parameters
➔ Channel name
7 characters
Inp.. x
or
Ext.c..x
Short designation. It is
shown in all diagram
representations.
v Chapter 3.8 “Text entry”
Channel
description
(external
analog inputs and
counters)
Configuration
➔ Analog inputs
➔ External input
1—36
External counter 1—2
➔ Addit’l parameters
➔ Channel
description
2 x 20 characters
Meas. inp. x
(external input)
or
external event
counter x
Detailed description. It is
additionally shown in the
two numerical displays.
v Chapter 3.8 “Text entry”
Parameter Value/selection Description
