JUMO LOGOSCREEN - Configuration - Group configuration

81
4 Configuration parameters
Configuration ➔ Group configuration
Parameter Value/selection Description
Group status Configuration
➔ Group config.
➔ Group 1 — 6
➔ Group status
Off,
Display only,
Displ.+store
Displ.+store.: the channels
in the group are shown in
the diagrams and stored in
the memory.
Group name Configuration
➔ Group config.
➔ Group 1 — 6
➔ Group name
16 characters
Group x
v Chapter 3.8 “Text entry”
Input signal
(analog channels,
group 1 — 6)
Configuration
➔ Group config.
➔ Group 1 — 6
➔ Analog channels
➔ Analog channel
1—6
➔ Input
signal
Off,
Analog inp.1 — 12,
Ext. Inp. 1 — 36,
Counter 1 — 2
Ext. counter 1 — 2
Group 1: A. inp. 1 — 6
Group 2: A. inp. 7 — 12
Assignment of the
hardware inputs to the
channels of the group
Line width
(analog channels,
group 1 — 6)
Configuration
➔ Group config.
➔ Group 1 — 6
➔ Analog channels
➔ Analog channel
1—6
➔ Line width
Thin,
Thick
For diagram representation
Alarms
(analog channels,
group 1 — 6)
Configuration
➔ Group config.
➔ Group 1 — 6
➔ Analog channels
➔ Analog channel
1—6
➔ Alarms
Off,
Activated
Low limit
(analog channels,
group 1 — 6)
Configuration
➔ Group config.
➔ Group 1 — 6
➔ Analog channels
➔ Analog channel
1—6
➔ Low limit
-99999 to 0 to +99999
High limit
(analog channels,
group 1 — 6)
Configuration
➔
Group config.
➔ Group 1 — 6
➔ Analog channels
➔ Analog channel
1—6
➔ High limit
-99999 to 0 to +99999
