Jung Smart Control SC 1000 KNX - 4 Software Description; Software Specification

Art. No. SC 1000 KNX
4 Software description
4.1 Software specification
ETS search paths: - Push button / Push button, general / Smart Control
BAU used: TP-UART + µC
KNX type class: 3b device with cert. Physical layer + stack
Configuration: S-mode standard
AST type: "00"
Hex
/ "0"
Dec
PEI connector: no connector
Application program:
No. Short description Name Version from mask
version
1 Multifunctional application program incl.
touch sensor/pushbutton sensor
function, display function, room
temperature controller and timer.
Can be expanded to include 4
additional control surfaces using a
mechanical push-button extension
module.
Replaces application version 1.1
(extended scope of functions).
Smart Control
501512
1.2
for ETS3.0
Version f
and ETS 4
705
Page 20 of 347

Software specification
