Jung Smart Control SC 1000 KNX User Manual

Art. No. SC 1000 KNX
4.2.3 Object table
Number of communication objects: 200
(max. object number 254 - gaps in between)
Number of addresses (max): 254
Number of assignments (max): 255
4.2.3.1 Push-button extension module
Objects for rocker or button functions
Function: Switching
Object
h
0
Function
Switching
Name
B.Module rocker/
B.Module button 1
1,2
Type
1-bit
DPT
1.xxx
Flag
C, W, T,
(R)
3
Description 1-bit object for transmission of switching telegrams (ON, OFF).
Function: Dimming
Object
h
0
Function
Switching
Name
B.Module rocker/
B.Module button 1
1,2
Type
1-bit
DPT
1.xxx
Flag
C, W, T,
(R)
3
Description 1-bit object for transmission of switching telegrams (ON, OFF).
Function: Dimming
Object
h
18
Function
Dimming
Name
B.Module rocker/
B.Module button 1
1,2
Type
4-bit
DPT
3.007
Flag
C, W, T,
(R)
3
Description 4-bit object for the transmission of relative dimming telegrams.
1: The number of rockers or buttons depends on the planned device variant.
2: The objects have been described for rocker 1 or button 1 as an example. The objects for the
other rockers/buttons are defined in the same way by shifting the object number and changing
the object name.
3: For reading, the R-flag must be set. The last value written to the object via the bus or by the
device will be read.
Page 25 of 347
Software "Smart Control 501511"
Object table
