ACX7348 DC Power Cables
You must supply DC power cables that meet the specicaons required by the local code, laws, and
standards. The ACX7348 supports a 6 AWG and 90 °C temperature-rated stranded copper wire.
CAUTION: You must ensure that power connecons maintain the proper polarity.
WARNING: For eld-wiring connecons, use copper conductors only.
WARNING: Make sure that DC power cables do not block access to ACX7348
components or lie on the ground where people can trip on them.
ACX7348 DC Power Cable Lugs
The accessory box shipped with the ACX7348 router includes the cable lugs that aach to the terminal
studs of each PSM. Figure 15 on page 31 shows the physical specicaons of the DC power cable lugs.
30
